• Up to 500 users can be coded using Smart enroll and delete technology
• A mounting template and installation kit are provided
• Three user levels: Normal – Requires single PIN code, Secure – Requires dual PIN codes, Master User
• Three access levels: Normal, Bypass, Secure
Integrated keypad for PIN entry
• Programmable PIN code length of 4 to 8-digits
• Programmable Backlight and active LED control
• Internal buzzer
• Vandal proof screw (special tool supplied)
• Supplied with mounting template for easy installation
• Powered either by transformer (AC) or regulated power supply (DC)
• IP65 water-resistant and UV-resistant
• Two inputs: REX and Auxiliary
• Two Form C, 2 Amp outputs: Lock Strike and Auxiliary
• Two tri-colored status/programming LEDs
• Ten programmable auxiliary behavior modes including Door Ajar, Forced Door, Alarm Shunt, and Door Monitor
• Programmable chime and siren when using BL-D40 and ‘*‘ bell button
• Built-in optical back tamper

• 500 Users
• Code search feature for easy maintenance of user codes
• Three user levels: Normal – Requires single PIN code or Proximity card, Secure – Requires PIN code + Proximity card, Master User
• Three access levels: Normal, Bypass, Secure
• Integrated keypad for PIN entry
• Programmable PIN code length of 4 to 8-digits
• Programmable Backlight and active LED control
• Internal buzzer
• Suitable for mullion installations
• Vandal proof screw (special tool supplied)
• Supplied with mounting template for easy installation
• Powered either by transformer (AC) or regulated power supply (DC)
• IP65 water-resistant and UV-resistant
• Two inputs: REX and Auxiliary
• Two Forms C, 2 Amp outputs: Lock Strike and Auxiliary
• Two tri-colored status/programming LEDs
• Ten programmable auxiliary behavior modes including Door Ajar, Forced Door, Alarm Shunt, Door Monitor, and LED control
• Programmable Bell, chime, siren and strobe features available with BL-D40
• Programmable siren time (with BL-D40)
• Built-in case and optical back tamper
• Lockout feature on wrong entries (Keypad / Card Tamper)
• Programmable lock strike release time

• Supports 4 to 8-Digit PIN & Proximity credentials
• 2x6 Piezo Keypad for PIN & Prox entry and programming
• Smooth, attractive design, with all weather indoor and outdoor operation
• Large, highly visible piezoelectric Keypad
• Fully sealed and epoxy potted in a metal housing, meets IP68
• 2 tri-colored LEDs and an integral sounder for programming and operation
• User friendly menu system based on keypad, LED and sounder indicators
• Optical Back tamper detection output
• Default operation as a multi-format reader

• Supports 4 to 8-Digit PIN & Proximity credentials
• 2x6 Piezo Keypad for PIN & Prox entry and programming
• Smooth, attractive design, with all weather indoor and outdoor operation
• Large, highly visible piezoelectric Keypad
• Fully sealed and epoxy potted in a metal housing, meets IP68
• 2 tri-colored LEDs and an integral sounder for programming and operation
• User friendly menu system based on keypad, LED and sounder indicators
• Optical Back tamper detection output
• Default operation as a multi-format reader

• Supports 4 to 8-Digit PIN & Proximity credentials
• 2x6 Piezo Keypad for PIN & Prox entry and programming
• Smooth, attractive design, with all weather indoor and outdoor operation
• Large, highly visible piezoelectric Keypad
• Fully sealed and epoxy potted in a metal housing, meets IP68
• 2 tri-colored LEDs and an integral sounder for programming and operation
• User friendly menu system based on keypad, LED and sounder indicators
• Optical Back tamper detection output
• Default operation as a multi-format reader

• Selectable output formats: Wiegand 26-Bit or Clock & Data
• Excellent RFID card read range of up to 8 cm (3.15 in.)
• Wide range operating voltage: 5 to 16 VDC
• 45 cm (18 in.) pigtail cable
• RF Modulation: ASK at 125 kHz
• Internal sounder with external control option
• Tri-color LED with external control inputs
• External reader hold control
• Optical wall tamper detection
• Water-resistant with epoxy potting (IP65), suitable for indoor and outdoor applications
• Made of tough polycarbonate UV-resistant plastic
• Comes with mounting template for easier installation

• Supports 4- to 8-Digit PIN credentials
• Smooth, attractive design, with all-weather indoor and outdoor operation
• Large, high-visibility RED backlit keypad
• 2 tri-colored LEDs and an integral sounder for programming and operation
• User-friendly menu, based on keypad, LED and sounder indicators
• Back and cover optical tamper detection and output
• Automatically recognizes Rosslare’s PS-x25T intelligent power supply family converting it into a 500-user standalone controller with secure relays

• Supports 4- to 8-Digit PIN credentials
• Smooth, attractive design, with all-weather indoor and outdoor operation
• Large, high-visibility RED backlit keypad
• 2 tri-colored LEDs and an integral sounder for programming and operation
• User-friendly menu, based on keypad, LED and sounder indicators
• Back and cover optical tamper detection and output
• Automatically recognizes Rosslare’s PS-x25T intelligent power supply family converting it into a 500-user standalone controller with secure relays

• Supports 4- to 8-digit PIN credentials
• Smooth, attractive design, for all-weather indoor and outdoor operation
• Large, highly visible piezoelectric keypad
• 2 tri-colored LEDs and an integral sounder for programming and operation
• User-friendly menu system based on keypad, LED, and sounder indicators
• Optical back tamper detection output
• Default operation as a multi-format reader
• Automatically recognizes Rosslare’s PS-x25T intelligent power supply family converting it into a 500-user standalone controller with secure relays
• 8 selectable PIN transmission modes including options for key stream, binary, parity, and 2×6 matrix
• Supports Wiegand or Clock & Data transmission formats
• Comes with a mounting and drilling label
• 60 cm(23.6 in.) shielded interface cable

• Supports 4- to 8-Digit PIN credentials and 125 KHz EM type RFID cards and tags
• Smooth, attractive design, with all-weather indoor and outdoor operation
• Large, high-visibility unique illuminated piezoelectric keypad
• Optical back tamper detection output
• 2 tri-colored LEDs and an integral sounder for programming and operation
• User-friendly menu system based on keypad, LED, and sounder indicators
• Automatically recognizes a connection to PS-x25T intelligent power supplies and converts into a 500-user standalone controller with secure relays
• 8 selectable PIN transmission modes including options for Key Stream, Binary, Parity, and 3×4 Matrix
• Supports Wiegand or Clock & Data transmission formats
• 3 security levels (Controller mode): Bypass (free entry), Normal (card or PIN required) or Secure (card + PIN)
• Comes with a mounting and drilling label
• 60 cm (23.6 in.) shielded interface cable

• Supports 4- to 8-Digit PIN credentials and 125 KHz EM type RFID cards and tags
• Smooth, attractive design, with all-weather indoor and outdoor operation
• Large, high-visibility unique illuminated piezoelectric keypad
• Optical back tamper detection output
• 2 tri-colored LEDs and an integral sounder for programming and operation
• User-friendly menu system based on keypad, LED, and sounder indicators
• Automatically recognizes a connection to PS-x25T intelligent power supplies and converts into a 500-user standalone controller with secure relays
• 8 selectable PIN transmission modes including options for Key Stream, Binary, Parity, and 3×4 Matrix
• Supports Wiegand or Clock & Data transmission formats
• 3 security levels (Controller mode): Bypass (free entry), Normal (card or PIN required) or Secure (card + PIN)
• Comes with a mounting and drilling label
• 60 cm (23.6 in.) shielded interface cable

• Selectable output formats: Wiegand 26-Bit or Clock & Data
• Excellent RFID card read range of up to 10 cm (3.9 in.)
• Wide range operating voltage: 5 to 16 VDC
• 45 cm (18 in.) pigtail cable
• RF Modulation: ASK at 125 kHz
• Internal sounder with external control option
• Tri-color LED with external control inputs
• External reader hold control
• Optical wall tamper detection
• Water-resistant with epoxy potting (IP65), suitable for indoor and outdoor applications
• Made of tough polycarbonate UV-resistant plastic
• Comes with mounting template for easier installation

• Selectable output formats: Wiegand 26-Bit or Clock & Data
• Excellent RFID card read range of up to 10 cm (3.9 in.)
• Wide range operating voltage: 5 to 16 VDC
• 45 cm (18 in.) pigtail cable
• RF Modulation: ASK at 125 kHz
• Internal sounder with external control option
• Tri-color LED with external control inputs
• External reader hold control
• Optical wall tamper detection
• Water-resistant with epoxy potting (IP65), suitable for indoor and outdoor applications
• Made of tough polycarbonate UV-resistant plastic
• Comes with mounting template for easier installation

• Wiegand 26 Bit output format
• RFID read range up to 60cm (23.6")
• Operating voltage range of 10 to 16 VDC
• 70cm (27.6") shielded interface cable
• Backed by Rosslare’s International Guarantee and service with ISO9001 (Certified TUV Rhineland) level business and manufacturing operations
• RF Modulation: ASK at 125 kHz
• Compatible with standard, passive EM type, cards and tags
• Internal buzzer
• LED control input
• Optical wall tamper detection
• Water-resistant with epoxy potting (IP65) suitable for indoor and outdoor applications
• Made of tough polycarbonate UV-resistant plastic

• 500 PIN users
• Smooth attractive design, with anti-vandal construction
• Highly-visible blue backlit keypad
• 3 operational Security Levels can be selected with special PIN codes
• Supports up to 8-digit PIN codes, with timed wrong code lockout after several wrong attempts
• 2 tri-colored LEDs and integral sounder for programming and operational indications
• Removable terminal blocks for unit wiring
• Optical tamper detection
• Automatic internal heater prevents key freeze at -20°C (4°F)
• 10 programmable modes for auxiliary input and output (2 Amp Form C Relay)
• 2 Amp Form C Lock Strike Relay, for fail-safe and fail-secure, with input for REX
• Supports: Door Ajar, Forced, Shunt, Monitor, and Secure mode
• Door bell key feature operation (from ‘*’ bell key), with Rosslare’s accessory BL-D40

• Built-in 125 kHz RFID card reader
• 500 users can have PIN and / or RFID user credentials for granting access
• Smooth attractive design, with anti-vandal construction
• Highly-visible blue backlit keypad
• 3 operational Security Levels can be selected with special PIN codes
• Supports up to 8-digit PIN codes, with timed wrong code lockout after several wrong attempts
• 2 tri-colored LEDs and integral sounder for programming and operation
• Wide range of low voltage AC/DC power input
• Optical tamper detection output
• Automatic internal heater prevents key freeze at -20°C (4°F)
• 10 programmable modes for auxiliary input and output (2 Amp Form C Relay.)
• 2 Amp Form C Lock Strike Relay, for fail-safe and fail-secure, with input for REX
• Supports: Door Ajar, Forced, Shunt, Monitor, and Secure mode
• Door bell key feature operation (from ‘*’ bell key), with Rosslare’s accessory BL-D40

• 500 Users
• Code search feature for easy maintenance of user codes
• Three user levels: Normal – Requires single PIN code or Proximity card, Secure – Requires PIN code + Proximity card, Master User
• Three access levels: Normal, Bypass, Secure
• Integrated keypad for PIN entry
• Programmable PIN code length of 4 to 8-digits
• Integrated proximity card reader
• Programmable Backlight and active LED control
• Internal buzzer
• Suitable for mullion installations
• Vandal proof screw (special tool supplied)
• Supplied with mounting template for easy installation
• Powered either by transformer (AC) or regulated power supply (DC)
• IP65 water-resistant and UV-resistant
• Two inputs: REX and Auxiliary
• Two Forms C, 2 Amp outputs: Lock Strike and Auxiliary
• Two tri-colored status/programming LEDs
• Ten programmable auxiliary behavior modes including Door Ajar, Forced Door, Alarm Shunt, Door Monitor, and LED control
• Programmable Bell, chime, siren and strobe features available with BL-D40
• Programmable siren time (with BL-D40)
• Built-in case and optical back tamper
• Lockout feature on wrong entries (Keypad / Card Tamper)
• Programmable lock strike release time

• Up to 500 users can be coded using Smart enroll and delete technology
• A mounting template and installation kit are provided
• Three user levels: Normal – Requires single PIN code, Secure – Requires dual PIN codes, Master User
• Three access levels: Normal, Bypass, Secure
Integrated keypad for PIN entry
• Programmable PIN code length of 4 to 8-digits
• Integrated proximity card reader
• Programmable Backlight and active LED control
• Internal buzzer
• Vandal proof screw (special tool supplied)
• Supplied with mounting template for easy installation
• Powered either by transformer (AC) or regulated power supply (DC)
• IP65 water-resistant and UV-resistant
• Two inputs: REX and Auxiliary
• Two Form C, 2 Amp outputs: Lock Strike and Auxiliary
• Two tri-colored status/programming LEDs
• Ten programmable auxiliary behavior modes including Door Ajar, Forced Door, Alarm Shunt, and Door Monitor
• Programmable chime and siren when using BL-D40 and ‘*‘ bell button
• Built-in optical back tamper

• 500 PIN users
• Smooth attractive design, with anti-vandal casing
• Highly-sensitive Piezo metal keys
• 3 operational Security Levels can be selected with special PIN codes
• Supports up to 8-digit PIN codes, with timed wrong code lockout after 3 wrong attempts
• 2 tri-colored LEDs and integral sounder for programming and operation
• Wide range of low voltage AC/DC power input
• Optical tamper detection output
• 10 programmable modes for auxiliary input and output (3 Amp Form C Relay)
• 3 Amp Form C Lock Strike Relay, for fail-safe and fail-secure
• Two inputs: REX and Auxiliary
• Supports: Door Ajar, Forced, Shunt, Monitor, and Secure mode
• Door bell key feature operation (from ‘*’ bell key), with Rosslare’s accessory BL-D40

• 500 PIN users
• Smooth attractive design, with anti-vandal casing
• Highly-sensitive Piezo metal keys
• 3 operational Security Levels can be selected with special PIN codes
• Supports up to 8-digit PIN codes, with timed wrong code lockout after 3 wrong attempts
• 2 tri-colored LEDs and integral sounder for programming and operation
• Wide range of low voltage AC/DC power input
• Optical tamper detection output
• 10 programmable modes for auxiliary input and output (3 Amp Form C Relay)
• 3 Amp Form C Lock Strike Relay, for fail-safe and fail-secure
• Two inputs: REX and Auxiliary
• Supports: Door Ajar, Forced, Shunt, Monitor, and Secure mode
• Door bell key feature operation (from ‘*’ bell key), with Rosslare’s accessory BL-D40

• Up to 8 in of read range
• Contactless Digital Radio Frequency Identification (RFID) technology
• Compliant with the Wiegand communication protocol
• IP67 compliant, weather resistant
• Tamper resistant
• UL Listed
• 5 year warranty

• Up to 7 in of read range
• Contactless Digital Radio Frequency Identification (RFID) technology
• Compliant with the Wiegand communication protocol
• IP67 compliant, weather resistant
• Tamper resistant
• UL Listed
• 5 year warranty

• Up to 15 ft of read range
• Contactless smartcard reader solution with mobile access support
• Digital Radio Frequency Identification (RFID) platform
• Supports both sector and card serial number (CSN) reads
• Offers the option of mobile access credentials loaded on Bluetooth Low Energy (BLE) enabled smartphones or contactless smartcard module
• IP67 compliant, weather resistant
• Tamper resistant
• UL Listed
• 5 year warranty

• Up to 5 in of read range
• Contactless Digital Radio Frequency Identification (RFID) technology
• Compliant with the Wiegand communication protocol
• IP67 compliant, weather resistant
• Tamper resistant
• UL Listed
• 5 year warranty

• Up to 5 in of read range
• Contactless Digital Radio Frequency Identification (RFID) technology
• Compliant with the Wiegand communication protocol
• IP67 compliant, weather resistant
• Tamper resistant • UL Listed
• 5 year warranty

• Up to 200 ft of read range
• Ultra high frequency (UHF) technology
• Receiver range covers a 360-degree radius and does not need to be installed in line-of-sight to the Transmitters to function
• Read range can be extended using a separate dipole antenna
• Equipped with a potted proximity or contactless smartcard module
• IP65 compliant, weather resistant
• UL Listed
• 5 year warranty

• Supports 4- to 8-digit PIN credentials
• Smooth, attractive design, for all-weather indoor and outdoor operation
• Large, highly visible blue backlit keypad
• User-friendly menu system based on keypad, LED, and sounder indicators
• Back and cover optical tamper detection and output
• Comes with a mounting and drilling label, security screw, and toolset to prevent unauthorized opening
• 60 cm(23.6 in.) shielded interface cable

• Up to 15 ft of read range
• Contactless smartcard reader solution with mobile access support
• Digital Radio Frequency Identification (RFID) platform
• Supports both sector and card serial number (CSN) reads
• Offers the option of mobile access credentials loaded on Bluetooth Low Energy (BLE) enabled smartphones or contactless smartcard module
• IP67 compliant, weather resistant
• Tamper resistant
• 5 year warranty

• Up to 15 feet of read range
• Keypad with contactless smartcard and mobile credential access support
• Digital Radio Frequency Identification (RFID) platform
• Supports both sector and card serial number (CSN) reads
• Offers the option of mobile access credentials loaded on Bluetooth Low Energy (BLE) enabled smartphones or contactless smartcard module
• IP67 compliant, weather resistant
• Tamper resistant
• Lifetime warranty

Support DIP physical setting for simple configuration Easy installation, supports wall-mount and pole-mount Support PoE 24V power supply Support IEEE 802.11 a/n/ac protocol Wireless speed up to 867Mbps Equipped with IP65 shell to prevent harsh weather from rain, dust and sun Excellent transmitting power and receiving sensitivity up to 1.5 miles in ideal conditions

2-in-1 Wireless bridge and PoE switch 5*10/100Mbps RJ45 port Supports DC 12-52V or POE 48-56V input Supports RS-485 signal control Supports IEEE 802.11 a/n protocol Wireless speed up to 300Mbps 5.8G wireless bridge transmission distance can reach 1.5 miles in ideal conditions Professional outdoor shell design, IP55 dustproof and water resistant protection level Dual PoE Output

Up to 15 feet of read range Keypad with contactless proximity and mobile credential access support Digital Radio Frequency Identification (RFID) platform Supports both sector and card serial number (CSN) reads Offers the option of mobile access credentials loaded on Bluetooth Low Energy (BLE) enabled smartphones or contactless proximity module IP67 compliant, weather resistant Tamper resistant Lifetime warranty *Products are in compliance with NDAA Section 889 Part B Guidelines

Up to 15 feet of read range Keypad with contactless proximity and mobile credential access support Digital Radio Frequency Identification (RFID) platform Supports both sector and card serial number (CSN) reads Offers the option of mobile access credentials loaded on Bluetooth Low Energy (BLE) enabled smartphones or contactless proximity module IP67 compliant, weather resistant Tamper resistant Lifetime warranty *Products are in compliance with NDAA Section 889 Part B Guidelines

The DR-B9000 is a USB scanner equipped with fingerprint identification module to acquire highresolution images with the most rugged and advanced optical sensor. The comfortable, ergonomic design ensures superior performance, accuracy, and durability based on unique Fingerprint Biometric Technology. This device can be used with Rosslare’s AY-B9xxx series of biometric terminals and controllers, and can enroll fingerprints directly into the software.

The AY-B9120BT networked fingerprint reader has a built-in EM (125 kHz ASK) RFID card reader with a capacity for 20,000 fingerprint credential templates with liveness check and high-speed operation. A smartphone interface is built-in with a Bluetooth 4.0 system to read Rosslare BLE-ID™ credentials and work with Rosslare BLE-Admin™ configuration apps for iOS and Android. Up to 2000 terminals may be managed by our AxTraxNG™ version 27.7.x.x and above, and by RosslareBio9000 Client/Server management suite for Windows OS. It supports up to 16 PC clients for enrollment and template distribution, which is ideal for networked fingerprint system operation and deployment. This product features the latest design and engineering to achieve a best-in-class solution when you need “Security that lasts

The AY-B9250BT networked fingerprint reader has a built-in MIFARE (13.56 MHz ) RFID card reader with a capacity for 20,000 fingerprint credential templates with liveness check, and high-speed operation. A smartphone interface is built-in with a Bluetooth 4.0 system to read Rosslare BLE-ID™ credentials and work with Rosslare BLE-Admin™ configuration apps for iOS and Android. Up to 2000 terminals may be managed by our AxTraxNG™ version 27.7.x.x and above, and by RosslareBio9000 Client/Server management suite for Windows OS. It supports up to 16 PC clients for enrollment and template distribution, which is ideal for networked fingerprint system operation and deployment. This product features the latest design and engineering to achieve a best-in-class solution when you need “Security that Lasts

The AY-B9350 is a high-performance Face and Fingerprint recognition reader with MIFARE® 13.56 MHz and EM 125 kHz card reader. It has an Android OS with a touch LCD. The dual IR/RGB camera has a motorized tilt for face finding, making the unit user friendly regardless of the height of the user. Advanced features include support for 100,000 fingerprint templates, 10,000 (1:1) & 2,000 (1:N) face templates, and innovative algorithms with liveness check. Connection is easy with TCP/IP, RS-485, Wiegand in/out (26-/34-Bit). The terminal can be set up easily using the AxTraxNG Client software. Alternatively, it is compatible with Rosslare’s standalone RosslareBio 9000 management software that is perfect for interfacing with existing third-party systems. This product features the latest design and engineering to achieve a best-in class solution.

• MD-81 functionality built-in • Wide range of UHF credential form factors available • UHF read range up to 6 m (19 ft) UHF credential cannot be installed in RF-proof vehicles. • Supports Bluetooth communication for Rosslare BLE-ID™ smartphone apps for Android and iOS • Can read up to 10 credentials per second or down to 1 credential per second (programmable) • IP67 water and dust resistant, IK10 vandal resistant • RGB LED used for operational indication

• MD-81 functionality built in • Wide range of UHF credential form factors available • UHF read range up to 12 m (39 ft) • Supports Bluetooth communication for Rosslare BLE-ID™ smartphone apps for Android and iOS • Can read up to 10 credentials per second or down to 1 credential per second (programmable) • IP65 for indoor and outdoor use • RGB LED used for operational indication

• 500 PIN users
• Smooth attractive design, with anti-vandal construction
• Highly-visible blue backlit keypad
• 3 operational Security Levels can be selected with special PIN codes
• Supports up to 8-digit PIN codes, with timed wrong code lockout after several wrong attempts
• 2 tri-colored LEDs and integral sounder for programming and operational indications
• Removable terminal blocks for unit wiring
• Optical tamper detection
• Automatic internal heater prevents key freeze at -20°C (4°F)
• 10 programmable modes for auxiliary input and output (2 Amp Form C Relay)
• 2 Amp Form C Lock Strike Relay, for fail-safe and fail-secure, with input for REX
• Supports: Door Ajar, Forced, Shunt, Monitor, and Secure mode
• Door bell key feature operation (from ‘*’ bell key), with Rosslare’s accessory BL-D40

• Built-in 125 kHz RFID card reader
• 500 users can have PIN and / or RFID user credentials for granting access
• Smooth attractive design, with anti-vandal construction
• Highly-visible blue backlit keypad
• 3 operational Security Levels can be selected with special PIN codes
• Supports up to 8-digit PIN codes, with timed wrong code lockout after several wrong attempts
• 2 tri-colored LEDs and integral sounder for programming and operation
• Wide range of low voltage AC/DC power input
• Optical tamper detection output
• Automatic internal heater prevents key freeze at -20°C (4°F)
• 10 programmable modes for auxiliary input and output (2 Amp Form C Relay.)
• 2 Amp Form C Lock Strike Relay, for fail-safe and fail-secure, with input for REX
• Supports: Door Ajar, Forced, Shunt, Monitor, and Secure mode
• Door bell key feature operation (from ‘*’ bell key), with Rosslare’s accessory BL-D40

• Up to 15 feet of read range
• Keypad with contactless smartcard and mobile credential access support
• Digital Radio Frequency Identification (RFID) platform
• Supports both sector and card serial number (CSN) reads
• Offers the option of mobile access credentials loaded on Bluetooth Low Energy (BLE) enabled smartphones or contactless smartcard module
• IP67 compliant, weather resistant
• Tamper resistant
• Lifetime warranty
